FV19F5WSFB 02 – SYSTEM AND ELECTRICAL PARTS

Products

Position	Product
*06533	WCI G186041
1	WCI F126260
2	GROMMET SPACER
3	TOP EVAP PLATE
4	CLIP-HOUSING TO BRACKET
5	WCI F121366
6	HEAT EXCHANGER (NON-ILLUSTRATED)
7	WCI F126404
8	TOP EVAP SHELF
9	SCREW-CLAMP
10	WCI F96850
11	WCI F126255-2
12	SCREW CONTROL
13	WCI F126256
15	BRACKET - COLD CONTROL
16	TUBE
17	BOTTOM EVAP SHELF
19	SUPPORT FRONT RH (2)
20	SCREW (5)
21	WCI F128533
21	HARNESS
22	5303305677 Frigidaire Replacement Filter Dryer Filters
23	EXTERNAL CONDENSER (NON-ILLUSTRATED)
24	WCI F59872
25	5304455846 Frigidaire Refrigerator Clamp
26	216858001 Frigidaire Refrigerator Screw
27	5303006412 Frigidaire Refrigerator Cover Mounting Strap
27	CLAMP COVER
27	WCI F128645
28	WCI F127580
28	WCI F128644
29	CLIP
29	WCI F127579
30	WCI F127581
30	OVERLOAD (NON-ILLUSTRATED)
31	RELAY (NON-ILLUSTRATED)
31	WCI F128640
31	WCI F127795
32	216498900 Frigidaire Refrigerator Grommet
33	WCI F124019
33	WCI F127799
33	WCI F128639
34	SLEEVE
35	WCI F59211
36	WCI F126234
37	SUPPORT FRONT LH (2)
