FWS645RBT0 05 – CONSOLE & CONTROLS

Products

Position	Product
1	BACKSHEET
2	131243700 Frigidaire Screw
3	WCI 131237800
4	SCREW (2)
5	134680100 Frigidaire Pressure Switch
8	131205100 Frigidaire Screw
9	WCI 131047000
12	END CAP-L.H.-WHITE
12A	WCI 131122712
13	END CAP-R.H.-WHITE
13A	WCI 131122702
14	WCI 5303286526
15A	WCI 131140702
15	WCI 131140701
16	WCI 131140601
16A	WCI 131140602
18	WCI 131251700
18A	WCI 131252000
19	WCI 131297306
20	WCI 131165600
21	131243800 Frigidaire Screw
21A	131168200 Frigidaire Dryer Screw
24A	WCI 131141102
24	131858004 Frigidaire Control Knob, White
25	Spacer,washer ,timer shaft
26	CLIP-CONSOLE MTG
30	COVER-CAP-LH-WHITE
30A	WCI 131122612
31	COVER-CAP-RH-WHITE
31A	WCI 131122602
