G24PCL3 06 – BURNER, MANIFOLD AND GAS CONTROL

G24PCL3 06 – BURNER, MANIFOLD AND GAS CONTROL

Written by

in

G24PCL3 06 – BURNER, MANIFOLD AND GAS CONTROL

Products

PositionProduct
15308007974 Frigidaire Pressure Regulator
2WCI 08014560
3TUBE-PILOT
4NUT – WING
5WCI 5308013927
6BAFFLE-OVEN BURNER
7WCI 5308013855
8TUBE OVEN SUPPLY
9WCI 08008363
10TUBE-OVEN PILOT
11LOXIT-NUT
12NUT
13SUPPORT-OVEN SAFETY VALVE
14PILOT-OVEN
15WCI 5308013942
16WCI 08008361
17STRAP – PILOT SHIELD
19WCI 5303131057
21SUPPORT-TOP BURNER
23Burner,top ,rear
24BURNER-TOP FRONT
25WCI 5300009126
