G30CL3 04 – BODY PARTS

Products

Position	Product
*14544	WCI 08067722
1	WCI 08014019
2	WCI 08068052
3	WCI 08008012
4A	WCI 08011552
4	SHIELD – HEAT RH
5	WCI 08014027
6	WCI 08008022
7	WCI 3205578
8A	318348801 Frigidaire Oven Left Side Door Hinge
8	HINGE – DOOR RH
9	WCI 08011484
10	WCI 08068027
11	WCI 3018282
12	SCREW – LEVELING (4)
13	WCI 08008036
14	BASE-RAIL (2)
15C	WCI 3018995
15	WCI 3018347
15	OVEN LINER-SIDE RH
15A	OVEN LINER-SIDE LH
16	BOTTOM – OVEN
17A	WCI 3017172
17	WCI 3017171
18	SUPPORT – REAR (2)
19	WCI 3017173
20	WCI 08012600
21	WCI 3107174
22	BACK – MAIN
23	WCI 08008357
24	5303912606 Frigidaire Oven Range Spark Module 2+0 4 Large Terminals
