G30LPNL1 07 – BODY PARTS

Products

Position	Product
*43100	SHIELD-FLUE, (NON-ILLUSTRATED)
*43100	ANTI-TIP KIT (NOT ILLUSTRATED)
*43100	3051218 Frigidaire Oven Plate
1	SPACER-BODYSIDE, (8)
3	CHAN-DOOR HINGE (2)
4	WCI 3203394
5	WCI 3203082
6	COVER-OVEN FRONT
7	316204402 Frigidaire Oven Flue
8	316542102 Frigidaire Flue Gasket
9	COVER-IGNITOR
10	BURNER BOX BOTTOM
11	WCI 5303269543
11	WCI 5303269545
12	SCREW-LEVELING
13	316067902 Frigidaire Oven Rack
14A	INSUL – OVEN BACK (NON-ILLUSTRATED)
14	BTTM-OVEN
14B	INSULATION, OVEN WRAPPER
15	5303284616 Frigidaire Range Bulb Clip Thermostat
16	COVER-VENT
16A	316064600 Frigidaire Oven Support
17	WCI 5303270160
18	3203010 Frigidaire Clip
