G30PNL3 06 – BURNER, MANIFOLD AND GAS CONTROL

G30PNL3 06 – BURNER, MANIFOLD AND GAS CONTROL

Written by

in

G30PNL3 06 – BURNER, MANIFOLD AND GAS CONTROL

Products

PositionProduct
1WCI 5303016997
2WCI 3204972
3WCI 3204974
4ABOLT VALVE MTG
4WCI 3202796
6TUBING-TOP PILOT, DUAL
7CAP-TOP PILOT
8WCI 3201276
9Tubing`thermo/pilot `3/16 ,alum
10WCI 3203395
11WCI 3018603
13WCI 3203265
145303013272 Frigidaire Oven Nut
15TUBE – ALUM THERMO./SAFETY W/ FIT.
16WCI 3204583
175304506427 Frigidaire Oven Range Surface Burner (White)
185304506426 Frigidaire Oven Top Rear Burner
19SHIELD-PILOT, STAINLESS STEEL, (2)
20WCI 5303201277
