G31BPNL2 06 – BURNER, MANIFOLD AND GAS CONTROL

G31BPNL2 06 – BURNER, MANIFOLD AND GAS CONTROL

Written by

in

G31BPNL2 06 – BURNER, MANIFOLD AND GAS CONTROL

Products

PositionProduct
1WCI 5303016997
2WCI 3204972
3WCI 3204974
4WCI 3202796
4ABOLT VALVE MTG
5WCI 5303211123
6CAP-TOP PILOT, (2)
7WCI 3201276
8Tubing`thermo/pilot `3/16 ,alum
9WCI 3203395
10WCI 3018603
11WCI 3203391
12WCI 3203265
135303013272 Frigidaire Oven Nut
14TUBE – ALUM THERMO./SAFETY W/ FIT.
15WCI 3204583
165304506427 Frigidaire Oven Range Surface Burner (White)
175304506426 Frigidaire Oven Top Rear Burner
18SHIELD-PILOT, STAINLESS STEEL, (2)
19WCI 5303201277
