G32BNL2 07 – BODY PARTS

Products

Position	Product
*36041	3051218 Frigidaire Oven Plate
*36041	WCI 3131190
*36041	COVER-VENT
*36041	WCI 3131252
1	SPACER-BODYSIDE, (8)
3A	5304515659 Frigidaire Oven Power Cord
3	CHAN-DOOR HINGE (2)
4	WCI 3203082
5	WCI 3131660
6	316282700 Frigidaire Oven Screw
7	316204402 Frigidaire Oven Flue
8	316542102 Frigidaire Flue Gasket
9	CHANNEL-BURNER BOX
10	BURNER BOX BOTTOM
11	PNL-BODYSIDE RH-ALMOND
11A	PNL-BODYSIDE LH-ALMOND
12	SCREW-LEVELING
13	316067902 Frigidaire Oven Rack
14	BTTM-OVEN
14A	INSULATION, OVEN WRAPPER
14B	INSUL – OVEN BACK (NON-ILLUSTRATED)
15A	WCI 08067961
15	5303284616 Frigidaire Range Bulb Clip Thermostat
16	316539800 Frigidaire Oven Retainer
17A	316064600 Frigidaire Oven Support
17	SHIELD-FLUE, (NON-ILLUSTRATED)
18A	ANTI-TIP KIT (NOT ILLUSTRATED)
18B	COVER-POWER CORD, (NON-ILLUSTRATED)
18	WCI 3131180
19A	COVER-OVEN FRONT
19	3203010 Frigidaire Clip
20	COVER-IGNITOR
