GAS148P1A1 02 – CABINET PARTS

Products

Position	Product
1B	NAMEPLATE REAR GRILLE (NON-ILLUSTRATED)
1	SHELL-CABINET
1A	WCI 5303210207
2	SEAL-BOTTOM
3	WCI 5303002608
4	BRACKET
5	SCREW-WOOD
6	ANGLE – TOP WINDOW
7	WCI 3001980
8	WCI 3202495
9	WCI 3202497
10	ACCORDIAN (2)
11	WCI 3002801
13	CLIP-SPRING (NON-ILLUSTRATED)
14	RETAINER-HORIZ LOUVER (NON-ILLUSTRATED)
15	WCI 5303212503
16	LOUVER-HORIZ
17	SEAL TOP & SIDE
18	FILTER-AIR
19	WCI 3017299
20	WCI 5303281623
21	DOOR
22	HINGE – DOOR
23A	RAIL-FILTER RH (NON-ILLUSTRATED)
23	RAIL-FILTER LH (NON-ILLUSTRATED)
24	WCI 3017304
25	WCI 5303017300
26	WCI 5303017340
27	KNOB – SLIDE, SWITCH
28	WCI 5303212508
29	WCI 5303001775
30	WCI 5303001984
31	WCI 3016224
32	WCI 3016225
33	BRACKET – SUPPORT
34	SCREW – SILL SUPT
35	NUT – BRACKET
36	SCREW – SUPPORT, 4
37	316205500 Frigidaire Oven Nut
38	WCI 08012680
39	WCI 3202498
