GCD14CJ0 03 – CABINET PARTSadmin2025-04-26T09:29:36+00:00GCD14CJ0 03 – CABINET PARTS
Products
| Position | Product |
|---|
| 1 | WCI G174747-10 |
| 2 | TUBE, INSULATION (2) |
| 3 | WCI G174733 |
| 4 | WCI G174734 |
| 5 | BASE-CABINET |
| 6 | CLIP (4) |
| 7 | LEG-LEVELING (2) |
| 8 | NUT, ANCHOR (2) |
| 9 | WCI G166912 |
| 10 | TAPPING, PLATE (2) |
| 11 | SHIM, HINGE |
| 12 | BRACKET, HINGE, LOWER |
| 13 | 5303001321 Frigidaire Refrigerator Lower Hinge Pin |
| 16 | WASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET) |
| 17 | WCI G142220 |
| 19 | BRACKET, HINGE CENTER |
| 20 | TRIM, COFFEE |
| 21 | BRACKET, TOP HINGE |
| 21A | TAPPING PLATE (2) |
| 22 | 241710601 Frigidaire Refrigerator Screw |
| 23 | WCI G183861 |
| 24 | COVER HINGE, COFFEE |
| 25 | 215667501 Frigidaire Refrigerator Ice Tray Primary |
| 26 | WCI G178294-01 |
| 27 | WCI G174655-19 |
| 27A | SWITCH SLIDE |
| 27B | 5304455650 Frigidaire Refrigerator Screw |
| 28 | SOCKET LIGHT |
| 29 | 316538904 Frigidaire Oven Lamp Light |
| 30 | TUBE |
| 31A | WCI G107080 |
| 31 | WCI G162205-09 |
| 32 | WCI G176554-01 |
| 33 | WCI 3001335 |
| 34 | WCI 3916133 |
| 35B | SPACER-MULLION MOUNTING (2) (NON-ILLUSTRATED) |
| 35A | WASHER (2) |
| 35 | SCREW, BRACKET MOUNTING (4) |
| 36 | WCI G187921 |
| 37 | CLAMP, MULLION MOUNTING |
| 38 | SCREW (5) |
| 39 | WCI 3016980 |
| 40 | WCI G163220 |
| 41 | 5309918806 Frigidaire Refrigerator Light Switch Door |
| 42 | WCI 3001542 |
| 43 | WCI 3001327 |
| 44 | WCI 3001541 |
