GDG18CA 02 – FRONT VIEW (SERIES 03)

Products

Position	Product
NI	DOWEL PIN FOR HANDLE
NI	MAY 314077
NI	MAY Y313927
NI	MAY Y313911
NI	MAY Y313541
NI	MAY Y304648
NI	MAY Y304384
NI	LABEL, LINT SCREEN INSTR.
NI	MAY 212276
NI	213007 Whirlpool Screw #12
NI	W10169313 Whirlpool Door Switch Kit
001	WP62739 Whirlpool Nut
002	MAY 204051
003	SCREW & FSTNER ASSY (FT. PNL)
004	MAY 204445
005	WP210385 Whirlpool Lock Nut
006	WP210684 Whirlpool Dishwasher Leveling Leg Pad
008	MAY 212519
009	SCREW, BUSHINGS
012	MAY 213099
013	WP355214 Whirlpool Screw
017	LEG, ADJUSTABLE (W/NUT)—S
019	MAY Y303204
026	MAY Y303420
027	MAY Y303703
030	MAY Y304577
031	MAY Y304579
041	W10176519 Whirlpool Leveling Feet
044	306436 Whirlpool Washer Dryer Door Catch and Plastic Strike
047	SLEEVE, ACCESS DOOR RUBBER
050	MAY Y313907
051	MAY Y313908
054	CLIP, DOOR LINER
061	WPY314137 Whirlpool Rubber Foot
