GEA1314A19 05 – CABINET

GEA1314A19 05 – CABINET

Written by

in

GEA1314A19 05 – CABINET

Products

PositionProduct
1WCI 5303276179
15304455650 Frigidaire Refrigerator Screw
2WCI 5308000081
3Nut,push-on
4WCI 3206110
55308000010 Frigidaire Refrigerator Evaporator Fan Blade
7RING-FAN ORIFICE
8G187559 Frigidaire Refrigerator Bushing
9WCI 5303205118
10NUT, “U“ TYPE, NO. 8-15(A), FAN MOTOR MOUNT (NOT ILLUSTRATED)
10WCI 3206119
115303208309 Frigidaire Refrigerator Plug Hole
12BUTTON – DECORATIVE PLUG
135300158289 Frigidaire Evaporator Fan Motor
14BRACKET-MOTOR MTG, REAR
17WCI 3206146
18SUPPORT-COIL COVER
19TUBE-RUBBER
22PLUG-BUTTON, ALMOND, UPR HINGE HOLES
23WCI 5303269702
24WCI 5303207353
25WCI 5303001361
25WCI 5308000056
27SCREW-LEVELING, (2)
30WCI 3206136
32PLUG-BUTTON
34WCI 5308000186
35BRACKET-CTR HINGE
36WCI 5308000184
37TRIM-CABINET CORNER, ALMOND
38WCI 3206100
38TAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED)
39SHIM – UPPER HINGE
42241710601 Frigidaire Refrigerator Screw
455304455651 Frigidaire Refrigerator Screw
565303001321 Frigidaire Refrigerator Lower Hinge Pin
57WCI 3206135
59SCREW – MULLION (2)
83WCI 5308000107
83PLUG, BUTTON, CABINET LINER (NI)
