GF204KXD3 06 – BODY PARTS

Products

Position	Product
1	GROMMET-MAINTOP
2	GROMMET
3	PANEL BODYSIDE-ALMD
4	SUPPORT-CONTROL PANEL
5B	OVEN LINER TOP
5A	OVEN LINER-SIDE LH
5C	OVEN LINER BACK
5	OVEN LINER-SIDE RH
6	FRAME-FRONT
7A	HINGE ASSY-RH
7	318348801 Frigidaire Oven Left Side Door Hinge
8	WCI 5308013916
9	SPRING-OVEN DOOR
10	WCI 5303016128
11	OVEN BOTTOM
12	SUPPORT-OVEN BOTTOM
14A	RAIL-BASE, LH
14	Rail,base ,RH
15	ANTI-TIP KIT
16	MAIN BOTTOM
17	WCI 3202740
18	INSUL BACK & TOP
19	WCI 5303271410
20	SUPPORT-REAR OVN (2)
21	WCI 3017173
21A	BURNER BOX
23A	SHIELD-BURNER BOX LH
23	SHIELD-BURNER BOX RH
23B	CLIP BACKSPLASH CORNER
24	WCI 5303210891
25	WCI 5303210892
