GF410HXW5 07 – BROILER DRAWER PARTS

Products

PositionProduct
1WCI 3131021
2WCI 3016973
35304504568 Frigidaire Drawer Assembly
4WCI 3018344
5WCI 3017184
65303013272 Frigidaire Oven Nut
7SPACER HANDLE (2)
85303292012 Frigidaire Oven Screw
9WCI 08013882
10PANEL – BLACK
11HINGE – RH
11AHINGE – LH
12SPRING (2)
13ATRACK LEFT HAND
13TRACK RIGHT HAND
