GF501KXD3 05 – BURNER, MANIFOLD AND GAS CONTROL

Products

Position	Product
1	5308007974 Frigidaire Pressure Regulator
2	WCI 3131081
3	SLIDE BAR
4A	WCI 5300009126
4	WCI 5303210474
5	BAFFLE-OVEN BURNER
6	WCI 5303202752
7	TUBE-OVEN FEED
8	LOCK NUT
9	TERMINAL BLOCK
10	COVER - OVEN SAFETY VALVE
11	WCI 08008051
12	SUPPORT-OVEN SAFETY VALVE
13	WCI 5308009419
14	5303935066 Frigidaire Oven Flat Igniter 17" Leads
15	CAM-VALVE
16	WCI 5303131057
17	WCI 5303131094
18	SPRING - SLIDE BAR
19	WCI 5303210471
20	IGNITER-TOP BURNER 36``
21	BURNER - TOP REAR
22	BURNER-TOP FRONT
23	WCI 5303131099
