GF501KXD3 06 – BODY PARTS

Products

Position	Product
*52489	WCI 19100180271
1	GROMMET-MAINTOP
2	GROMMET
3	PANEL BODYSIDE-ALMD
4	SUPPORT-CONTROL PNL
5	OVEN LINER-SIDE RH
5	OVEN LINER-BACK
5	OVEN LINER-TOP
5	OVEN LINER-SIDE LH
6	FRAME-FRONT
7A	HINGE ASSY-RH
7	318348801 Frigidaire Oven Left Side Door Hinge
8	SEAL OVEN DOOR
9	SPRING-OVEN DOOR
10	WCI 3016158
11	OVEN-BOTTOM
12	SUPPORT-OVEN BOTTOM
14A	Rail,base ,RH
14B	RAIL-BASE, LH
14	BASE RAIL
15	ANTI-TIP KIT
16	MAIN BOTTOM
17	INSULATION WRAPPER
18	WCI 3131044
19	WCI 5303212609
20	SUPPORT-REAR OVN (2)
21	WCI 3017173
22	BURNER BOX
23B	CLIP,BODYSIDE
23	SHIELD-BURNER BOX RH
23A	SHIELD-BURNER BOX LH
24	CHANNEL - MAIN WIRE
25	WCI 3131047
26	5303912606 Frigidaire Oven Range Spark Module 2+0 4 Large Terminals
27	WCI 5303210892
28	WCI 5303210891
