GF620ND2 07 – BODY PARTS

GF620ND2 07 – BODY PARTS

Written by

in

GF620ND2 07 – BODY PARTS

Products

PositionProduct
*51792WCI 3131192
*51792COVER-POWER CORD, (NON-ILLUSTRATED)
*517933051218 Frigidaire Oven Plate
*517925304515659 Frigidaire Oven Power Cord
*51793DIAGRAM, WIRING (NOT FOR PURCHASE)
*51792WCI 08067961
*51793WCI 3131660
1SPACER-BODYSIDE, (8)
3WCI 316007002
5WCI 3203082
6316282700 Frigidaire Oven Screw
7316204402 Frigidaire Oven Flue
8316542102 Frigidaire Flue Gasket
9CHANNEL-BURNER BOX
10BURNER BOX BOTTOM
11WCI 5303269545
11WCI 5303269543
12SCREW-LEVELING
13316067902 Frigidaire Oven Rack
14CWCI 08010570
14BINSUL – OVEN BACK (NON-ILLUSTRATED)
14BTTM-OVEN
14AINSULATION, OVEN WRAPPER
155303284616 Frigidaire Range Bulb Clip Thermostat
163203010 Frigidaire Clip
17A316064600 Frigidaire Oven Support
17COVER-VENT
18WCI 5303270160
19COVER-OVEN FRONT
19AANTI-TIP KIT (NOT ILLUSTRATED)
19BSHIELD-FLUE, (NON-ILLUSTRATED)
20COVER-IGNITOR
