GF750ND1 04 – BURNER, MANIFOLD AND GAS CONTROL

Products

PositionProduct
*36310BRACKET BURNER MTG
1WCI 5303210379
2BAFFLE-OVN BURNER
3WCI 08067935
4WCI 3131290
5BURNER-TOP-DOUBLE
63016993 Frigidaire Oven Retainer
7BURNER TUBE-RF & LF
8WCI 5303011569
9WCI 5303011570
10NUT COMPRESSN (4)
11FERRULE (4)
12IGNITER-TOP BURNER, BASE, (2)
13WCI 3018861
14WCI 5303017542
15ELBOW 1/2 NP TO 9/16-24
16WCI 5303207999
175303935068 Frigidaire Flat Igniter
185303935066 Frigidaire Oven Flat Igniter 17" Leads
195303912606 Frigidaire Oven Range Spark Module 2+0 4 Large Terminals
20WCI 5303208640
21NUT
23TUBE-ALUM 3/8 REG/MANIFOLD PIPE
24TUBE-VALVE TO REGUL
25TUBE-VALVE TO MIXER ELBOW
26AWASHER-BLACK
265303208499 Frigidaire Safety Gas Valve
275303935125 Frigidaire Pressure Regulator
28316091600 Frigidaire Oven Bracket
295303013272 Frigidaire Oven Nut
30WCI 08068015
31NUT, SPECIAL
