GF780KXD4 06 – BURNER, MANIFOLD AND GAS CONTROL

Products

PositionProduct
*51967SPACER (NON-ILLUSTRATED)
15308007974 Frigidaire Pressure Regulator
2MANIFOLD
3SLIDE BAR
4WCI 5303131099
5WCI 3131064
6WCI 08068028
7WCI 5300009126
8CAM-VALVE
9WCI 5303131057
10SPRING – SLIDE BAR
11BURNER-TOP FRONT
12Burner,top ,rear
13IGNITER-TOP BURNER 48“
14WCI 5303210471
15MICRO – SWITCH
165303935066 Frigidaire Oven Flat Igniter 17" Leads
17BURNER-OVEN BAKE
18Baffle,oven burner
19WCI 3131866
20WCI 3017415
21WCI 08011509
22PIN-ELBOW MIXER
23WCI 3131871
24BURNER-BROILER
255303935067 Frigidaire Range Oven Flat Igniter 3-1/4"
