GL6050VL0 02 – CABINET

Products

Position	Product
	350930 Whirlpool White Spray Paint
	Platinum (Uncut)
	72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
	Toast
	72113 Whirlpool Touch-Up Paint
	Golden Harvest
	Golden Harvest (Uncut)
	WPL 72112
	Paint, Spray (13 Oz.) (Platinum)
	Enamal, Toast (1 Qt. Uncut)
	WPL LIT3390374
	WPL LIT3391353
	WPL LIT3391774
	350938 Whirlpool Spray Gun
	350956 Whirlpool Spray Assembly
	72017 Whirlpool Appliance Touch-Up Paint White
	799344 Whirlpool Refrigerator Paint
	WP72107 Whirlpool Touchup
	Leveler (Thinner)
	Almond (Uncut)
1	Panel, Rear
3	WP3390631 Whirlpool Screw
4	Cap, End (L.H.)
5	Stop, Push-In Top
7	Cap, End (R.H.)
8	WP489069 Whirlpool Compactor Screw
9	WP693995 Whirlpool Screw
10	339392V Whirlpool Dryer Lint Filter Screen
11	Cover, Lint Screen (Almond)
11	Cover, Lint Screen (White)
12	WPW10044480 Whirlpool Hinge Assembly
12	WPW10044470 Whirlpool Hinge Assembly
13	W11693756 Whirlpool Screw Assembly
14	WPL 64211
16	Top (White)
16	Top (Almond)
18	WP94614 Whirlpool Terminal
19	Knob, Temperature Selector
21	Timer Assembly, 60 Hz.
30	Nut, Push-In (2)
31	Harness, Wiring
39	Switch, Push-To-Start
48	Timer Knob Assembly
53	Bracket, Control
54	Panel, Control
67	WP689559 Whirlpool Nut
72	Wire, Ground
75	353424 Whirlpool Connector
75	Connector (Door Switch)
76	WP694419 Whirlpool Buzzer Adjuster
79	Switch, Temperature (Variable)
81	Knob, Push-To-Start
84	WP596797 Whirlpool Terminal
