GLC3634HP5 01 – SECTION
Written by
in
GLC3634HP5 01 – SECTION
Products
Position
Product
1
Safer Cooking Tips
1
Literature Parts (Use & Care Guide)
1
Literature Parts (Installation Instructions)
1
Literature Parts (Wiring Diagram)
1
Literature Parts (Energuide Label)
2
Cooktop & Bracket Assembly (Designer White)
2
Cooktop & Bracket Assembly (Biscuit)
2
Cooktop & Bracket Assembly (White)
2
Cooktop & Bracket Assembly (Black)
3
WP486754 Whirlpool Compactor Screw
4
Bracket, Switch Mounting
5
W10823698 Whirlpool Surface Element Right Rear
5
W10823692 Whirlpool Dual Radiant Element
5
W10823699 Whirlpool Right Front Surface Element
5
W10823711 Whirlpool Surface Element Left Front and Right Rear
6
Spring, Locator
7
WP3191050 Whirlpool Infinite Switch
7
WP3191049 Infinite Switch Left Rear Right Front
7
WP4456027 Whirlpool Infinite Switch Right Rear
8
3183956 Whirlpool Oven Seal Switch
9
Light, Indicator
10
WP3196231 Whirlpool Knob
10
WP3196232 Whirlpool Knob
11
WP3400093 Whirlpool Screw
11
8186533 Whirlpool Hardware
12
Box, Burner
13
Bumper, Silicone
14
WP3196557 Whirlpool Screw
15
Seal, Inifinite Switch
17
WP486579 Whirlpool Air Conditioner Screw
20
Wire, 25` Roll (Black 14 Ga.)
20
Wire, 25“ Roll (White 14 GA.)
20
WP3400015 Whirlpool Screw
20
Wire (14 Ga. 200 c Brown)
20
Wire, 25` Roll (Red 14 Ga.)
20
WPL 4456015
20
W10355051 Whirlpool Cooktop Cleaner Affresh (10 Oz)
20
WPL 4456028
20
18 Ga. 80~c Rating (Red)
20
Wire (12 Ga. 150 c Black)
20
Wire (14 Ga. 150 c Yellow)
20
Wire (14 Ga. 150 c Orange)
20
Wire (14 Ga. 150 c Green)
20
Wire (14 Ga. 150 c Brown)
20
Hardware Asm.
20
242831 Whirlpool Oven Wire
20
W10491984 Whirlpool Switch Seal
20
1
20
Rail, Element (2)
20
4455364 Whirlpool Oven Support Bracket
20
WPL 3192737
20
WPL 4456063
←
