GLGT1041AS2 09 – LOWER CABINET/TOP

GLGT1041AS2 09 – LOWER CABINET/TOP

Written by

in

GLGT1041AS2 09 – LOWER CABINET/TOP

Products

PositionProduct
1134203900 Frigidaire Scr 6-32X.337 Pph D
2131168200 Frigidaire Dryer Screw
3A134075500 Frigidaire Bumper-LID
45304489657 Frigidaire Bar Hinge Kit
55303208743 Frigidaire Grommet
65303212872 Frigidaire Lid
9131390000 Frigidaire Door Catch-Strike
113204368 Frigidaire Screw-Strike
203204374 Frigidaire Pin
33131900200 Frigidaire Primary Valve
34131205500 Frigidaire Screw
35SNUBBER RING
36SHIPPING BLOCK
37WCI 131658900
38WCI 5303311213
41131302800 Frigidaire Drum Vane Screw
42WCI 131104303
43WCI 131422100
43A131422200 Frigidaire P-1 Self Level Leg Pad
44134548800 Frigidaire Washer Leg Levelling
45WCI 131346400
45A131346401 Frigidaire Pin
46WCI 134046600
47MARRIAGE BRACKET-RH
47AMARRIAGE BRACKET-LH
50Lid lock w/external sw
53WCI 131452510
54WCI 3204394
55134890500 Frigidaire Spring
56131243700 Frigidaire Screw
58WCI 131744202
