GM8131XEQ0 07 – DOOR, LIT/OPTIONAL

Products

Position	Product
	Literature Parts (Cookbook)
	Literature Parts (Tech Sheet)
	Literature Parts (Cooking Guide)
	Literature Parts (U & C Guide)
1	Door Assembly (White)
1	Door Assembly (Black)
2	Panel, Door (White Model)
2	Panel, Door (Black Model)
3	Glass (Black)
3	Glass (White)
4	Assembly, Door Frame
5	Choke Cover
6	Side Trim, Door
7	Top Trim, Door
8	Side Trim, Door
9	Bottom Trim, Door
10	Pin, Latch
11	Lever, Latch
12	Latch
13	Latch
14	30“ Built-In Kit MK8130XAQ (White)
14	27“ Built-In Kit MK8137XAB (Black)
14	27“ Built-In Kit MK8137XAQ (White)
14	Spring
14	30“ Built-In Kit MK8130XAB (Black)
