GPG39WNW2 07 – DOOR PARTS

GPG39WNW2 07 – DOOR PARTS

Written by

in

GPG39WNW2 07 – DOOR PARTS

Products

PositionProduct
1HANDLE-OVEN DOOR
2WCI 5303269511
3WCI 5303210960
45303208655 Frigidaire Reflector Assembly
5ALUM FOIL-B/G GLASS
6BRKT GLASS
7GLASS-OVEN DOOR, INNER
8FSTNR-NYLON SPACER (NON-ILLUSTRATED)
9SHIELD-INSULATION, WHITE
10INSULATION-OVEN DOOR
11SCREW, CR PAN HD SEMS, 8-32BP X 1.00
12GLASS-OVEN DOOR, HEAT BARRIER, (2)
13WCI 5303209517
14SEAL-ROPE, 0.25 DIA
15WCI 5303209511
16WCI 5303209515
175303131601 Frigidaire Oven Seal
