GPM638BDL5 06 – LOWER BODY PARTS

GPM638BDL5 06 – LOWER BODY PARTS

Written by

in

GPM638BDL5 06 – LOWER BODY PARTS

Products

PositionProduct
*27952WCI 08067977
*27952WCI 08068008
*279525300809968 Frigidaire Dishwasher P-1 Washer
1SOCKET-OVEN LIGHT
3WCI 08067809
4316116400 Frigidaire Oven Light Socket
5316538904 Frigidaire Oven Lamp Light
6WIRE-GLASS RETAINR
7AWCI 08067836
7WCI 08067765
8WCI 316007002
9CVR-HNG CUTOUT (2)
10WCI 08067986
11AWCI 08067992
11SHIELD-WALL REAR
12WCI 08067754
13WCI 3131672
14FSTNR-PUSH ON
14ASTUD SPACER (2) (NON-ILLUSTRATED)
15AWCI 08067957
15WCI 08067758
16WCI 08067728
17ROD, LIGHT
18WCI 08067924
19WCI 08067925
20WCI 08067993
21WCI 08067748
22WCI 08067989
23WCI 08067991
24WCI 08067956
25WCI 08067963
26ASHIELD-BI MTL LATCH
26316542102 Frigidaire Flue Gasket
26BWCI 08013188
27WCI 08010597
28WCI 08067976
29WCI 08067975
30WCI 08067757
31WCI 08067942
32WCI 08067985
33WCI 08067988
34WCI 08067990
35APNL-BDYSDE-RH-ALMD
35PNL-BDYSDE-LH-ALMD
36WCI 08010569
37316067902 Frigidaire Oven Rack
38WCI 08016608
39BROILER PAN
40B3131903 Frigidaire Door/Drawer Bumper
40WCI 08067931
40A316064600 Frigidaire Oven Support
41EINSULATION-WRAP (NON-ILLUSTRATED)
41BINSULATION, TOUCH (NON-ILLUSTRATED)
41D08067973 Frigidaire 0 Insulation
41AWCI 08067961
41FWCI 08068018
41WCI 08067750
41CINSULATION-BACK (NON-ILLUSTRATED)
423051162 Frigidaire Oven Range Front Broiler Drawer Glide
43WCI 08067743
43AWCI 08067744
44TRIM-VERTICAL BODYSIDE (2)
45WCI 08067958
