GPM638BDL8 06 – LOWER BODY PARTS

Products

Position	Product
*27952	WCI 08068008
*27952	WCI 08067977
*27952	5300809968 Frigidaire Dishwasher P-1 Washer
1	SOCKET-OVEN LIGHT
3	WCI 08067809
4	316116400 Frigidaire Oven Light Socket
5	316538904 Frigidaire Oven Lamp Light
6	WIRE-GLASS RETAINR
7	WCI 08067765
7A	WCI 08067836
8	WCI 316007002
9	CVR-HNG CUTOUT (2)
10	WCI 08067986
11	SHIELD-WALL REAR
11A	WCI 08067992
12	WCI 08067754
13	WCI 3131672
14	FSTNR-PUSH ON
14A	STUD SPACER (2) (NON-ILLUSTRATED)
15A	WCI 3200594
15	WCI 08067758
16	WCI 08067728
17	ROD, LIGHT
18	WCI 08067924
19	WCI 08067925
20	WCI 08067993
21	WCI 08067748
22	WCI 08067989
23	WCI 08067991
24	WCI 08067956
25	WCI 08067963
26	316542102 Frigidaire Flue Gasket
26A	SHIELD-BI MTL LATCH
26B	WCI 08013188
27	WCI 08010597
28	WCI 08067976
29	WCI 08067975
30	WCI 08067757
31	WCI 08067942
32	SHIELD-FRONT
33	WCI 08067988
34	WCI 08067990
35A	PNL B/S-LH (ALMOND)
35	PNL B/S-RH (ALMOND)
36	WCI 08010569
37	316067902 Frigidaire Oven Rack
38	WCI 08016608
39	BROILER PAN
40	WCI 08067931
40A	316064600 Frigidaire Oven Support
40B	3131903 Frigidaire Door/Drawer Bumper
41D	08067973 Frigidaire 0 Insulation
41A	WCI 08067961
41F	WCI 08068018
41E	INSULATION-WRAP (NON-ILLUSTRATED)
41C	INSULATION-BACK (NON-ILLUSTRATED)
41B	INSULATION, TOUCH (NON-ILLUSTRATED)
41	WCI 08067750
42	3051162 Frigidaire Oven Range Front Broiler Drawer Glide
43	WCI 08067743
43A	WCI 08067744
44	TRIM-VERTICAL BODYSIDE (2)
45	WCI 08067958
