GPM638BDL9 06 – LOWER BODY PARTS

GPM638BDL9 06 – LOWER BODY PARTS

Written by

in

GPM638BDL9 06 – LOWER BODY PARTS

Products

PositionProduct
*29868ANTI-TIP KIT (NOT ILLUSTRATED)
*298685300809968 Frigidaire Dishwasher P-1 Washer
*29868SHIELD LATCH
*29868WCI 08068008
1SOCKET-OVEN LIGHT
4316116400 Frigidaire Oven Light Socket
5316538904 Frigidaire Oven Lamp Light
6WIRE, GLASS RETAINER
7AWCI 08067836
75304524341 Frigidaire Lens
8WCI 316007002
9CVR-HNG CUTOUT (2)
10WCI 08067986
11AWCI 08067992
11SHIELD-WALL REAR
12WCI 08067754
13WCI 3131672
14BWCI 3200594
14ASTUD SPACER (2) (NON-ILLUSTRATED)
14FSTNR-PUSH ON
16WCI 3203082
17ROD, LIGHT
19WCI 08067925
20WCI 08067993
21WCI 08067748
22WCI 08067989
23WCI 08067991
24WCI 08067956
25WCI 08067963
26BWCI 08013188
26ASHIELD-BI MTL LATCH
26316542102 Frigidaire Flue Gasket
27WCI 3203218
28WCI 08067976
29WCI 08067975
30WCI 08067757
31WCI 08067942
32SHIELD-FRONT
33WCI 08067988
34WCI 3200836
35APNL B/S-LH (ALMOND)
35PNL B/S-RH (ALMOND)
36WCI 08010569
37316067902 Frigidaire Oven Rack
38WCI 08016608
39BROILER PAN
40EINSULATION OVEN BACK (NON-ILLUSTRATED)
40CWCI 08067961
40F08067973 Frigidaire 0 Insulation
40HWCI 08068018
40B3131903 Frigidaire Door/Drawer Bumper
40DINSULATION, OVEN WRAPPER
40GINSULATION-WRAP (NON-ILLUSTRATED)
40A316064600 Frigidaire Oven Support
40WCI 08067931
423051162 Frigidaire Oven Range Front Broiler Drawer Glide
43WCI 08067743
43AWCI 08067744
44TRIM-VERTICAL BODYSIDE (2)
45WCI 08067958
