GPM638BDW9 06 – LOWER BODY PARTS

Products

Position	Product
*29868	5300809968 Frigidaire Dishwasher P-1 Washer
*29868	WCI 08068008
*29868	ANTI-TIP KIT (NOT ILLUSTRATED)
*29868	SHIELD LATCH
1	SOCKET-OVEN LIGHT
4	316116400 Frigidaire Oven Light Socket
5	316538904 Frigidaire Oven Lamp Light
6	WIRE, GLASS RETAINER
7	5304524341 Frigidaire Lens
7A	WCI 08067836
8	WCI 316007002
9	CVR-HNG CUTOUT (2)
10	WCI 08067986
11A	WCI 08067992
11	SHIELD-WALL REAR
12	WCI 08067754
13	WCI 3131672
14B	WCI 3200594
14A	STUD SPACER (2) (NON-ILLUSTRATED)
14	FSTNR-PUSH ON
16	WCI 3203082
17	ROD, LIGHT
19	WCI 08067925
20	WCI 08067993
21	WCI 08067748
22	WCI 08067989
23	WCI 08067991
24	WCI 08067956
25	WCI 08067963
26A	SHIELD-BI MTL LATCH
26	316542102 Frigidaire Flue Gasket
26B	WCI 08013188
27	WCI 3203218
28	WCI 08067976
29	WCI 08067975
30	WCI 08067757
31	WCI 08067942
32	SHIELD-FRONT
33	WCI 08067988
34	WCI 3200836
35	B/S-LH-(WHITE)
35A	B/S-RH-(WHITE)
36	WCI 08010569
37	316067902 Frigidaire Oven Rack
38	WCI 08016608
39	BROILER PAN
40A	316064600 Frigidaire Oven Support
40	WCI 08067931
40F	08067973 Frigidaire 0 Insulation
40B	3131903 Frigidaire Door/Drawer Bumper
40H	WCI 08068018
40G	INSULATION-WRAP (NON-ILLUSTRATED)
40E	INSULATION OVEN BACK (NON-ILLUSTRATED)
40C	WCI 08067961
40D	INSULATION, OVEN WRAPPER
42	3051162 Frigidaire Oven Range Front Broiler Drawer Glide
43A	WCI 08067744
43	WCI 08067743
44	TRIM-VERTICAL BODYSIDE (2)
45	WCI 08067958
