GRSS2652AD8 15 – ICE & WATER DISPENSER

GRSS2652AD8 15 – ICE & WATER DISPENSER

Written by

in

GRSS2652AD8 15 – ICE & WATER DISPENSER

Products

PositionProduct
*241806601 Frigidaire Refrigerator Water Connector
*Harness, wiring, door, dispenser
*242200102 Frigidaire Refrigerator Clip
1*#218976439 Frigidaire Refrigerator Water Inlet Tube
1#218976438 Frigidaire Refrigerator Tube
8#5304533221 Frigidaire I&W Module Assembly
95304527100 Frigidaire Refrigerator Guide
235304527043 Frigidaire Tray
24*5304519199 Frigidaire Refrigerator Spring
245304527083 Frigidaire Refrigerator Paddle Assembly
38C#5304523072 Frigidaire Refrigerator Switch
38*242294101 Frigidaire Refrigerator Gasket
38#5304527032 Frigidaire Refrigerator User Interface Assembly Black
