GSIW36CH1 05 – SHELVES AND SUPPORTS

GSIW36CH1 05 – SHELVES AND SUPPORTS

Written by

in

GSIW36CH1 05 – SHELVES AND SUPPORTS

Products

PositionProduct
1A5304455852 Frigidaire Refrigerator Screw
1CHANNEL-RS & LS
2WCI G171608-08
3WCI G172436-16
4TRIM-SHELF-FRONT (4)
5WCI G171654-15
6WCI G171260-15
7WCI G169711-04
8WCI G186057
9131420300 Frigidaire Screw
10PAN-STORAGE-LOWER
11WCI G169724-04
12BASKET-FREEZER
12ASCREW-TRIM MTG (2) (NON-ILLUSTRATED)
13WCI G168625-08
14HANGER-BASKET RS
15HANGER-BASKET LS
16SHELF-FREEZER-BOTTOM
17ACLIP-TRIM (NON-ILLUSTRATED)
17TRIM-CLIP ON (3)
18SHELF-FREEZER-CTR (2)
19A5304509705 Frigidaire Refrigerator Grommet
19WCI G163925-02
20WCI G174571-01
20ALABEL-SHELF-LOWER (NON-ILLUSTRATED)
21ALABEL-SHELF-UPPER (NON-ILLUSTRATED)
21WCI G174556-01
22TANK-WATER
23WCI G163938
24TUBE-CUT TO SIZE (2)
25WCI G166705
26WCI G186058
