GTL142BK3 04 – CABINET PARTS

GTL142BK3 04 – CABINET PARTS

Written by

in

GTL142BK3 04 – CABINET PARTS

Products

PositionProduct
*62513PLUG, BUTTON, CABINET LINER (NI)
29WASHER, .34 X .62 X .05, NYLON
30HINGE BRACKET – BOTTOM
31SHIM-LOWER HINGE
34WCI 5308000186
35BRACKET-CTR HINGE
36WCI 5308000184
37WCI 5303202338
38BTAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED)
38BRACKET-UPPER HINGE
39SHIM – UPPER HINGE
42241710601 Frigidaire Refrigerator Screw
43WCI 5300188673
43AWCI 5308009760
43BWCI 5308009790
44WCI 5308009773
455304455651 Frigidaire Refrigerator Screw
46BOLT-ROLLER MTG, HEX WASHER HEAD, 1/4-28 X 1/2, (2)
565303001321 Frigidaire Refrigerator Lower Hinge Pin
59WCI 5308012258
815304455650 Frigidaire Refrigerator Screw
83WCI 5308000107
