GTN155AH2 05 – SYSTEM AND AUTOMATIC DEFROST PARTS
Written by
in
GTN155AH2 05 – SYSTEM AND AUTOMATIC DEFROST PARTS
Products
Position
Product
1A
HOT TUBE REPAIR KIT (NON-ILLUSTRATED)
1
WCI G178225
2
BRACKET-CONDENSER MOUNTING (4)
3
5308000039 Frigidaire Refrigerator Screw
3A
WASHER
4
5303305677 Frigidaire Replacement Filter Dryer Filters
5
WCI 3201679
6
218843801 Frigidaire Refrigerator Screw
7
HARNESS-WIRING, CONTROL/DIVIDER,(NON-ILLUSTRATED)
8
WIRING HARNESS, COMPRESSOR,
9
CORD-ELECTRIC POWER
10
WCI G183584
11
5304455651 Frigidaire Refrigerator Screw
12
5303001199 Frigidaire Refrigerator Wiring Harness Clamp
13
240396801 Frigidaire Refrigerator Tube Clamp
15
EXCHANGER-HEAT
16
WCI G162432-02
17
EVAPORATOR
18
5308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
19
INSULATOR
20
BLOCK, EVAPORATOR, RH
21
PLUG, EVAPORATOR INSULATION BLOCK, R H
22
BLOCK, LEFT SIDE
23
5303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
24
WCI G162822
25
218513300 Frigidaire Refrigerator Compressor Mount Grommet
26
WASHER, COMPRESSOR MOUNTING (4)
27
CLIP, COMPRESSOR MOUNTING (4)
28A
DEFROST PAN & NUT
28
PAN-DEFROST-ORIG COMPRESSOR
28B
5303307583 Frigidaire Refrigerator P1 Pad Noise Reduction
29
NUT, LOCK
30
PAN RETAINER KIT-SERVICE
31
WCI 3916012
32
RELAY-TL
33
WCI 3202863
34
WCI 08016583
35
STRAP-COVER
36
WCI 3202891
37
WCI 5303018427
38
STRAP CAPACITOR
←
