GTN198CH1 04 – SHELVES AND SUPPORTS

GTN198CH1 04 – SHELVES AND SUPPORTS

Written by

in

GTN198CH1 04 – SHELVES AND SUPPORTS

Products

PositionProduct
*44431WCI G107080
*444315304455649 Frigidaire Refrigerator Screw
1PAN-CRISPER, RIGHT SIDE
2215667501 Frigidaire Refrigerator Ice Tray Primary
3PAN-CRISPER, LEFT SIDE
4SUPPORT, CRISPER COVER
5WCI 3001493
6ARAIL-STRAIGHT RS (NON-ILLUSTRATED)
6RAIL-OFFSET LS
7WCI G172434-32
8WCI 3001491
9WCI G172434-42
10WCI G177390-21
11MEAT PAN
12WCI G187195-01
13WCI 3200810
14215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
15TOP-REFRIGERATOR
15ASCREW (5)
165309918806 Frigidaire Refrigerator Light Switch Door
17WCI 08002662
18WCI 3200369
19SCREW, BRACKET MOUNTING (4)
20STRAP, MULLION MOUNTING
21WASHER (2)
22SPACER (NON-ILLUSTRATED)
23DIVIDER, CENTER
23AHARNESS, WIRING
24BOTTOM, FC
25316538904 Frigidaire Oven Lamp Light
26WCI 08000129
27WCI G174655-18
28WCI 3001339
29WCI 3001335
30WCI 3001670
31TUBE
