GTN198WD1 03 – CABINET PARTS

GTN198WD1 03 – CABINET PARTS

Written by

in

GTN198WD1 03 – CABINET PARTS

Products

PositionProduct
*12694BUTTON, LINER
1COVER, TOP HINGE, ALMOND
1COVER HINGE, COFFEE
1COVER HINGE, WHEAT
1COVER HINGE, WHITE
1COVER, TOP HINGE, AVOCADO
2TAPPING PLATE (2)
2BRACKET, TOP HINGE
3WCI G183861
4241710601 Frigidaire Refrigerator Screw
5WCI G103903
6WASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET)
7ROLLER FRONT, ADJUSTABLE (2)
8NUT, ANCHOR (2)
8LEG-LEVELING (2)
8ROLLER, REAR (2)
95304455651 Frigidaire Refrigerator Screw
10BOLT ROLLER (2)
11SPRING-ROLLER (2)
12BOLT-ROLLER (2)
13WASHER
14SUPPORT, ROLLER (2)
15HINGE-BRACKET-BOTTOM
16SHIM, HINGE
175303001321 Frigidaire Refrigerator Lower Hinge Pin
19WCI 08010092
20DEFLECTOR AIR
21WCI G162178
22SHELF-FREEZER STEP
23WCI 3202338
23WCI 3202336
23WCI 3202340
23CORNER TRIM-AVOCADO
23WCI 3202339
24WCI G174747-09
24WCI G174747-11
24WCI G174747–01
24WCI G174747-10
24WCI G174747-08
25WCI 3001328
26DAMPER FAN COVER
27NUT, DAMPER MOUNTING
28WCI 3001333
29WCI 3001496
31SPOUT DRAIN TUBE
32PIN PUSH SPOUT (2)
33RING, SEAL (NON-ILLUSTRATED)
33WCI 3001458
345308000010 Frigidaire Refrigerator Evaporator Fan Blade
35WCI 08000124
36G187559 Frigidaire Refrigerator Bushing
375300158289 Frigidaire Evaporator Fan Motor
38WCI G185302
39BRACKET-CONNECTOR
39WCI G185303
39218843801 Frigidaire Refrigerator Screw
40TUBE, INSULATION (2)
41NUT, ORIFICE (2)
41WCI G177529
415304455650 Frigidaire Refrigerator Screw
41PLUG-SHORT TEST HOLE (NON-ILLUSTRATED)
42BRACKET, HINGE CENTER
43SCREW, BRACKET MOUNTING (4)
44WCI G142220
45WCI G177534
46WCI 08000302
475304455852 Frigidaire Refrigerator Screw
48WCI G189341
49SCREW (3) (NON-ILLUSTRATED)
50WCI G163669
51WCI G166912
52WCI G174733
53WCI G174734
