GTN217CH2 03 – CABINET PARTS

Products

Position	Product
1	COVER HINGE, COFFEE
2	WCI 08012843
2A	TAPPING PLATE (2)
3	WCI G183861
4	241710601 Frigidaire Refrigerator Screw
5	WCI G103903
6	WASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET)
7	ROLLER FRONT, ADJUSTABLE (2)
8	ROLLER, REAR (2)
9	5304455651 Frigidaire Refrigerator Screw
10	BOLT ROLLER (2)
11	SPRING-ROLLER (2)
12	BOLT-ROLLER (2)
13	WASHER
14	SUPPORT, ROLLER (2)
15	HINGE-BRACKET-BOTTOM
16	SHIM, HINGE
17	5303001321 Frigidaire Refrigerator Lower Hinge Pin
19	WCI G490004-02
20	DEFLECTOR AIR
21	WCI G162178
22	WCI G166912
23	WCI G174733
24	WCI G174734
25	NUT, ANCHOR (2)
26	DAMPER FAN COVER
27	NUT, DAMPER MOUNTING
28	WCI 3001333
29	WCI 3001451
30	LABEL-FAN CVR
31	SPOUT DRAIN TUBE
32	PIN-PUSH
33A	RING, SEAL (NON-ILLUSTRATED)
33	WCI 3001458
34	WCI G173705
35	RING, FAN ORIFICE
36	G187559 Frigidaire Refrigerator Bushing
37	5300158289 Frigidaire Evaporator Fan Motor
38	WCI G185302
39B	218843801 Frigidaire Refrigerator Screw
39A	WCI G164571
39	WCI G185303
40	TUBE, INSULATION (2)
41A	5304455650 Frigidaire Refrigerator Screw
41	WCI G184609
41B	NUT, ORIFICE (2)
41C	PLUG-SHORT TEST HOLE (NON-ILLUSTRATED)
42	BRACKET, HINGE CENTER
43	SCREW, BRACKET MOUNTING (4)
44	WCI G142220
45	WCI G177534
46	WCI 08000302
47	5304455852 Frigidaire Refrigerator Screw
48	WCI G189341
49	SCREW (3) (NON-ILLUSTRATED)
50	WCI G163669
51	WCI G174747-10
52A	BUTTON, LINER
52B	TAPPING, PLATE (2)
52	WCI 3202339
53	LEG-LEVELING (2)
