GTN217CH4 04 – SHELVES AND SUPPORTS

GTN217CH4 04 – SHELVES AND SUPPORTS

Written by

in

GTN217CH4 04 – SHELVES AND SUPPORTS

Products

PositionProduct
*267525304455649 Frigidaire Refrigerator Screw
1PAN-CRISPER, RH
2WCI 5303200810
2AWCI 5303001260
3PAN-CRISPER, LH
4SUPPORT-CRISPER CVR, ADJUSTABLE
5COVER-CRISPER
6WCI G187214-02
7WCI 5303209081
8SHELF, CANTILEVER, FULL WIDTH, WIRE
9WCI 5303209078
10FRAME-HALF (2)
11WCI 5303015407
12WCI 5318719501
13ASCREW-RAIL (2) (NON-ILLUSTRATED)
13WCI G187213-02
14WCI 3201453
15TOP-REFRIGERATOR
15AWCI 5303001380
165309918806 Frigidaire Refrigerator Light Switch Door
17WCI 5308002662
18WCI 5303200369
19WCI 5308012258
20WCI 5308010008
21WASHER, NO. 10 FLAT, 7/32 X 7/16 OD, STEEL (NI)
22SPACER-MULLION MTG, STEEL
23AHARNESS-DIVIDER (NON-ILLUSTRATED)
23WCI 5308013674
24BOTTOM PANEL-FRZR
25316538904 Frigidaire Oven Lamp Light
26SOCKET-LIGHT/LAMP
27CONTROL BOX
28LABEL-CONTROL BOX
29KNOB-CONTROL
30SWITCH-ENERGY SAVER, SLIDE TYPE
31TUBE
32215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
