GTN217WHD4 03 – CABINET PARTS

GTN217WHD4 03 – CABINET PARTS

Written by

in

GTN217WHD4 03 – CABINET PARTS

Products

PositionProduct
*36429PLUG, BUTTON, CABINET LINER (NI)
1WCI 5303001666
1COVER – HINGE-WHEAT
1COVER-UPPER HINGE, WHITE
1COVER-HINGE-AVOCADO
1COVER-UPPER HINGE, ALMOND
2BRACKET-UPPER HINGE
3SHIM – UPPER HINGE
5WASHER, .34 X .62 X .05, NYLON
6WASHER, .28 X .62 X .19, NYLON
7WCI 5308009760
8WCI 5308009773
95304455651 Frigidaire Refrigerator Screw
10BOLT-ROLLER MTG, HEX WASHER HEAD, 1/4-28 X 1/2, (2)
11WCI 5308009790
12BOLT-ROLLER ADJ, (2) (NON-ILLUSTRATED)
13WCI 5308011326
14SUPPORT, BASE (2)
15HINGE BRACKET – BOTTOM
15TAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED)
16SHIM-LOWER HINGE
175303001321 Frigidaire Refrigerator Lower Hinge Pin
18241710601 Frigidaire Refrigerator Screw
19CABINET BASE
20DEFLECTOR-AIR
21COVER – AIR DEFLECTOR
22COVER-HOLE, LOWER HINGE
23WCI 5303001286
24WCI 5303001287
25WCI 5308003584
26DAMPER-FAN COVER
27Nut,push-on
28WCI 5303001333
29WCI 3001451
30SCREW-LEVELING (4)
31WCI 5308000056
32WCI 5303001361
33WCI 5303001458
33WCI 5303207353
345308000010 Frigidaire Refrigerator Evaporator Fan Blade
35RING-FAN ORIFICE
36G187559 Frigidaire Refrigerator Bushing
375300158289 Frigidaire Evaporator Fan Motor
38WCI 5303001226
39WCI 5308000107
39218843801 Frigidaire Refrigerator Screw
39WCI 5303001227
40TUBE-RUBBER
41WCI 5303203044
41COVER, COIL
415304455650 Frigidaire Refrigerator Screw
41NUT-SPEED (2)
42BRACKET-CTR HINGE
43WCI 5308012258
44WCI 5308000184
45WCI 5303001470
46CHANNEL, RH & LH
475304455852 Frigidaire Refrigerator Screw
48WCI 5303015409
49WCI 5308016568
50SUPPORT-COIL COVER
51PLUG-BUTTON, WHITE
51PLUG-BUTTON, ALMOND, UPR HINGE HOLES
51BUTTON-HINGE-WHEAT
51BUTTON-HINGE-AVOCADO
51PLUG, COFFEE
52TRIM-CABINET CORNER, WHITE
52TRIM-CABINET CORNER, ALMOND
52WCI 5303202339
52WCI 5303202338
52CORNER
