GU980SCGZ0 01 – FRAME AND CONSOLE
Written by
in
GU980SCGZ0 01 – FRAME AND CONSOLE
Products
Position
Product
1
Console (Includes Insert) (Almond)
1
Console (Includes Insert) (White)
1
Console (Includes Insert) (Black)
3
Control, Electronic
4
675813 Whirlpool Thermal Fuse Kit
8
WP9743028 Whirlpool Dishwasher Frame
9
WP3380854 Whirlpool Door Latch Bolt
10
Lever, Latch White
10
Lever, Latch (Almond)
10
Lever, Latch
11
Shield, Switch
12
Pin, Switch (2)
13
Harness and Protector
14
3376405 Whirlpool Dishwasher Elbow
15
WP488234 Whirlpool Air Conditioner Screw
16
Cover, Timer
17
Motor, Dual
19
Panel Front (White Model)
19
Panel Front (Black Model)
19
Panel Front (Almond Model)
21
Barrier, Lower Vent
23
675782 Whirlpool Dishwasher Catch
26
WP3373234 Whirlpool Dishwasher Bearing
←
