GW30SPED1 02 – CONTROL PANEL

Products

Position	Product
*54503	WCI 08015925
1	COVER, WIRE.
2	5303935086 Frigidaire Oven Top Burner Switch Kit
3	THERMOSTAT
4A	IND LITE SURF UNIT
4	LIGHT-PILOT OVEN & CLEAN
5	LENS (2)
6	WCI 5308015771
7	PANEL-CONTROL
8	KNOBS (6)
9	WCI 5303282359
9A	WCI 5303282358
10	SUPPORT RH
10A	SUPPORT LH
11	BRACKET, HINGE (2)
12	BRACKET-THERMOSTAT
13	WCI 5305156401
14	WCI 5301167676
15	WCI 5301167678
16	BRACKET-MTG CLOCK
17	5308015487 Frigidaire Switch-Oven Light
