HA4290 Transmission Assembly
Written by
in
HA4290 Transmission Assembly
Products
Position
Product
NA
Wire Harness Assembly
NA
Transmission Sealant (Comment: Use as a sealant between transmission case and cover)
1
Retaining Ring
2
Coupling and Shaft Kit
3
Transmission Case Assembly
4
Packaged Bearing
5
Seal
6
Reduction Gear
7
Washer
8
Screw
9
Transmission Oil (Comment: 1 fill)
10
Gear and Stud Assembly
11
Screw
12
Washer
13
Washer
14
Input Pinion (Comment: Use with 28430 Transmission Assembly)
14
Drive Pinion (Comment: Use with 30946P Transmission Assembly)
15
Input Shaft
19
Washer
20
Screw
21
Transmission Cover Assembly
22
Bearing
23
Slide
24
Rack
25
Agitator Pinion
←
