HFS158DM1W 02 – CHEST FREEZER PARTS

Products

Position	Product
2	5303925238 Frigidaire Refrigerator Primary Condenser (O/S1)
4	PLUG-DRAIN
6	GROMMET
7	WCI F128979
8	WCI F300547
9	WCI F300554
17	WCI F129067
18	SUPPORT (4)
19	WCI F128513
20	WCI F129881
28	SCREW HINGE
29	297321900 Frigidaire Refrigerator Hinge Assembly
30	SPACER-HINGE
31	SCREW-HINGE
32	WCI F129166-S
33	WCI F129167
34	WCI F129164
38	WCI F121006
39	WCI F128894
40	FASTENER HANDLE (2)
42	297147700 Frigidaire Freezer Plastic Door Key
43	WCI F128024
44	WCI F127470
46	WCI F128897
47	WCI F128165
48	5303212828 Frigidaire Refrigerator Primary Clip
49	CLIP PANEL AND LOCK
50	HARNESS-LID
53	WCI F94491
54	WCI F92472
55	WCI F113848
56	WCI F94494
57	WCI F126469
58	WCI F128000
74	WIRE HARNESS
76	216036601 Frigidaire Refrigerator Screw
77	5303212614 Frigidaire Refrigerator Clip
78	WCI F127315
79	CONTROL TEMP
80	5303305677 Frigidaire Replacement Filter Dryer Filters
81	218513300 Frigidaire Refrigerator Compressor Mount Grommet
83	CLIP
84	PANEL
85	KNOB
86	SUPPORT
87	SCREW
88	WCI F300638
89	WCI F300398
90	WCI F300397
91	CLIP
93	5303006412 Frigidaire Refrigerator Cover Mounting Strap
95	216858001 Frigidaire Refrigerator Screw
98	5304464438 Frigidaire Compressor Run Capacitor
99	WCI F300579
