HFS180EM1W 02 – CHEST FREEZER PARTS

Products

Position	Product
2	5303925238 Frigidaire Refrigerator Primary Condenser (O/S1)
4	PLUG-DRAIN
6	WCI F300102
7	WCI F128979
8	WCI F300548
9	WCI F300555
17	WCI F129067
18	SUPPORT (4)
19	WCI F128513
28	SCREW HINGE
29	297321900 Frigidaire Refrigerator Hinge Assembly
30	SPACER HINGE WING
31	SCREW (8)
32	LID EXTERIOR-WHITE
33F	WCI 300786
38	WCI F121006
39	WCI F128894
40	FASTENER HANDLE (2)
42	297147700 Frigidaire Freezer Plastic Door Key
43	WCI F300788
44	WCI F300791
46	WCI F128898
47	WCI F128177
48	5303212828 Frigidaire Refrigerator Primary Clip
74	HARNESS-W/ PWR CORD
76	216036601 Frigidaire Refrigerator Screw
77	5303212614 Frigidaire Refrigerator Clip
78F	WCI 127315
79	CONTROL TEMP
80	5303305677 Frigidaire Replacement Filter Dryer Filters
81F	WCI 114221
83	CLIP
84	PANEL
85	KNOB
86	CONTROL KNOB
87	SCREW
88	WCI F300638
89	WCI F300398
90	WCI F300397
91	WCI F300749
93	5303006412 Frigidaire Refrigerator Cover Mounting Strap
95	216858001 Frigidaire Refrigerator Screw
97	WCI F128958
98	5304464438 Frigidaire Compressor Run Capacitor
99	WCI F300579
