JE1040WY02 BOTTOM PLATE & INTERNAL PARTS
Written by
in
JE1040WY02 BOTTOM PLATE & INTERNAL PARTS
Products
| Position | Product |
|---|---|
| 280 | OVEN LAMP |
| 1010 | GEN WB08X10006 |
| 1015 | GEN WB27X1065 |
| 1121 | GEN WB24X10015 |
| 1200 | GEN WB56X10042 |
| 1202 | BOTTOM PLATE SMALL |
| 1203 | BOTTOM PLATE, LEFT |
| 1205 | GEN WB06X0432 |
| 1206 | GEN WB18X10021 |
| 1210 | GEN WB01X1476 |
| 1417 | GEN WB26X0161 |
| 1422 | GEN WB26X0174 |
| 1423 | GEN WB38X10011 |
| 1428 | GEN WB27X1049 |
| 1430 | GEN WB24X10016 |
| 1433 | GEN WB27X10049 |
| 1437 | GEN WB06X10040 |
| 1438 | HIGH VOLTAGE CAPACITOR |
| 1439 | DIODE |
| 1445 | MONITOR SWITCH |
| 1446 | SENSING & 2ND LOCK SWIT. |
| 1475 | GEN WB06X0435 |
| 1476 | GEN WB02X9462 |
| 1477 | GEN WB06X10036 |
| 1492 | GEN WB06X0433 |
| 1508 | TURNTABLE |
| 1509 | GEN WB06X10035 |
| 1516 | GEN WB04X0186 |
| 1621 | GEN WB08X0313 |
| 4008 | GEN WB06X10037 |
| 4009 | GEN WB06X10038 |
| 4010 | GEN WB06X10039 |
| 4020 | HIGH VOLTAGE – COVER |
| 5511 | GEN WB06X0335 |
| 6012 | CLIP-STIRRER |
| 9999 | GEN 49-40013 |
| 9999 | GEN 31-20909 |
