JGBP27DEM6WW GAS & BURNER PARTS

Products

Position	Product
1	GEN 31-21329
1	GEN 31-21390
1	GEN 49-85194-1
2	WB03K10218 GE Oven Control Knob
3	WB28K10023 GE Oven Orifice
4	WB01K10037 GE Oven Economic Nut
5	MANIFOLD PANEL
8	WB01K10002 GE Oven Screw 8-32
9	BOX BURNER SP
10	WB35K10029 GE Oven Burner Box Insulation
11	WB02K10361 GE Oven Orifice Holder
12	WB18X31205 GE Oven Burner Box Harness
14	MANIFOLD PIPE
15	WB21K38 GE Oven Burner Valve
16	WB20K10021 GE Oven Thermostat
18	WB37K10012 GE Thermostat Cover
18	WB2K24 GE Oven Valve Cover
20	GEN WB28K10191
20	WB28K10188 GE Oven Rear Orifice H R 150N 9500
21	WB01K10066 GE Oven Screw 8 HD 10-32
22	GEN WB28K10192
22	WB28K10190 GE Oven Left Front Orifice
25	WB24K5022 GE Oven Rocker Switch
26	WB16K10035 GE Range Oven Burner Bar with Igniter
27	WB28K10168 GE Oven Burner Supply Tube
28	WB1X1293 GE Oven Screw
29	GEN WB28K10310
30	GEN WB16K10067
37	WB34K14 GE Igniter Cover
131	WB25T10041 GE Oven Lens
146	GEN WB02K0052
206	WB01K10091 GE Oven Screw
214	WB19K10041 GE Oven Safety Valve and Regulator Assembly
218	WB13K21 GE Oven Igniter with 7 Leads
219	WB49K10025 GE Range Deflector
219	OVEN DEFLECTOR
237	GEN WB28K10477
237	WB28X24772 GE Oven Gas Tube Connector
272	WB49K10045 GE Broil Shield
294	GEN WB63K10040
707	WB02K10267 GE Wire Clip
711	KNOB THERMOSTAT ASM
1006	WB01X23501 GE Oven Screw 8-32 Tapping Flat Head
