| 1 | MAIN BASE |
| 1 | GEN WB49X0383 |
| 1 | GEN WB07X1122 |
| 2 | SPACER, NOSE |
| 2 | GEN WB56X5754 |
| 2 | GEN WB07X1123 |
| 2 | SCREW, MTG. NOSE |
| 3 | NUT |
| 3 | WB19X10006 GE Oven Clock |
| 3 | GEN WB49X5219 |
| 3 | GEN WB02X1422 |
| 3 | GEN WB56X5755 |
| 4 | GEN WB03X0218 |
| 4 | GEN WB56X5756 |
| 5 | GEN WB56X5757 |
| 5 | GEN WB03X0463 |
| 6 | GEN WB56X5758 |
| 6 | GEN WB02X6659 |
| 6 | GEN WB03X0462 |
| 7 | SCREW - MT. TRIM |
| 7 | SPEEDNUT - MTG. TRIM TO |
| 8 | GEN WB07X0635 |
| 8 | GEN WB56X5792 |
| 9 | SCR 8 A IHW 3/8 S |
| 9 | GEN WB02X1973 |
| 9 | GEN WZ05X0132 |
| 9 | GEN WB56X5760 |
| 10 | GEN WB01X0068 |
| 10 | GEN WB56X5669 |
| 10 | GEN WB02X6671 |
| 11 | GEN WB49X5151 |
| 11 | GEN WB02X6668 |
| 12 | GEN WB02X6658 |
| 12 | GEN WB36X5347 |
| 13 | GEN WB02X3453 |
| 13 | OVEN SWITCH |
| 13 | GEN WB02X6486 |
| 13 | SCR 8-32 M PHR 3/16 S |
| 13 | GEN WB02X6494 |
| 13 | GEN WB49X5217 |
| 14 | GEN WB02X6404 |
| 15 | GEN WB10X5113 |
| 15 | GEN WB24X0176 |
| 16 | GEN WB02X6473 |
| 17 | NEON LAMP - 240V |
| 17 | GEN WB27X5108 |
| 18 | GEN WB24X5102 |
| 18 | SWITCH, LATCH RELEASE |
| 18 | TRIM SWITCH |
| 19 | GEN WB01X5220 |
| 19 | GEN WB02X6617 |
| 19 | GEN WB02X6490 |
| 19 | NUT, HEX |
| 19 | GEN WB02X3405 |
| 20 | GEN WB02X6274 |
| 20 | GEN WZ05X0234 |
| 21 | WB1X536 GE Oven Screw |
| 21 | GEN WB02X2006 |
| 21 | GEN WB02X6697 |
| 22 | GEN WB02X3291 |
| 22 | GEN WZ04X0372 |
| 22 | GEN WZ04X0369 |
| 22 | GEN WB02X3435 |
| 30 | GEN WB53X5081 |
| 31 | GEN WB49X5153 |
| 32 | GEN WB02X6857 |
| 32 | GEN WB02X6853 |
| 34 | GEN WB02X6855 |
| 35 | GEN WB15X0153 |
| 35 | GEN WB02X6854 |
| 36 | GEN WB10X5121 |
| 36 | SPEEDNUT - GRIP (4) |
| 37 | GEN WB24X5101 |
| 37 | GEN WB07X1151 |
| 37 | GEN WD02X0437 |
| 37 | GEN WB02X6699 |
| 38 | GEN WB02X3459 |
| 38 | GEN WB02X6698 |
| 39 | GEN WB09X0157 |
| 40 | GEN WB02X6557 |
| 40 | GEN WB07X1150 |
| 41 | GEN WB02X3334 |
| 41 | GEN WB56X5639 |
| 42 | GEN WB02X3335 |
| 42 | GEN WB01X5453 |
| 43 | GEN WB02X3336 |
| 43 | GEN WB48X5056 |
| 44 | GEN WB10X5110 |
| 44 | GEN WB36X0557 |
| 45 | SCREW & WASHER ASM |
| 46 | GEN WB10X5123 |
| 46 | GEN WB02X3333 |
| 47 | GEN WB10X5117 |
| 47 | SCR 8-32 T HXW 7/8 S |
| 48 | GEN WB02X3331 |
| 48 | GEN WB20X5041 |
| 49 | GEN WB20X5042 |
| 50 | GEN WB01X5471 |
| 50 | GEN WB02X6667 |
| 50 | GEN WB55X0419 |
| 51 | GEN WB02X3310 |
| 51 | GEN WB49X5184 |
| 52 | GEN WB02X6723 |
| 52 | GEN WB01X0439 |
| 52 | GEN WB27X5071 |
| 53 | GEN WB02X6609 |
| 53 | GEN WB02X3332 |
| 54 | GEN WB02X3436 |
| 55 | GEN WB18X5053 |
| 56 | SCREW MT. GRIP (4) |
| 56 | GEN WB08X5084 |
| 57 | GEN WB02X6856 |
| 57 | GEN WB09X0153 |
| 58 | GEN WB02X6852 |
| 59 | GEN WB55X0406 |
| 60 | GEN WB02X3285 |
| 61 | WB1X558D GE Oven Screw Package |
| 62 | GEN WB02X3312 |
| 62 | GEN WB02X3314 |
| 63 | GEN WB09X0154 |
| 64 | COVER & GUARD ASM. |
| 64 | WB1X500D GE Oven Screw Package |
| 65 | GEN WB09X0128 |
| 66 | WB2X3138 GE Oven Self-Clean Door Gasket |
| 67 | GEN WB02X3316 |
| 68 | GEN WB02X3313 |
| 68 | GEN WB02X2276 |
| 68 | GEN WB55X0407 |
| 69 | GASKET WINDOW |
| 70 | GEN WB36X5377 |
| 70 | GEN WB01X5476 |
| 70 | GEN WZ04X0238 |
| 70 | GEN WB36X0448 |
| 71 | GEN WB03X5562 |
| 71 | GEN WB01X0547 |
| 72 | GEN WB03X5563 |
| 72 | GEN WB01X0548 |
| 73 | GEN WB03X5564 |
| 73 | GEN WB49X0354 |
| 74 | GEN WB02X3317 |
| 74 | GEN WB02X3318 |
| 74 | GEN WB02X6729 |
| 75 | GEN WB55X0408 |
| 75 | GEN WB03X5584 |
| 76 | GEN WB02X6722 |
| 76 | GEN WB02X6706 |
| 76 | GEN WB02X3040 |
| 76 | WZ5X158D GE Screw Package of 12 |
| 77 | GEN WB02X3320 |
| 77 | GEN WB02X3319 |
| 77 | SCR 8-18 AB OVR 3/4 S |
| 77 | SPEEDNUT |
| 77 | GEN WB49X5183 |
| 78 | GEN WZ04X0386 |
| 78 | GEN WB24X5083 |
| 79 | WB1X119D GE Oven Range Washer |
| 79 | NEON LAMP 118V |
| 79 | GEN WB02X6624 |
| 80 | GEN WB02X6662 |
| 81 | GEN WB02X6511 |
| 82 | GEN WB02X6721 |
| 83 | GEN WB02X6510 |
| 84 | GEN WB02X6704 |
| 84 | WB1X5364 GE Oven Mounting Screw |
| 84 | GEN WB27X5052 |
| 85 | GEN WB02X6491 |
| 85 | GEN WB02X6664 |
| 86 | SCR 6-20 AB HXW 1/4 S |
| 86 | GEN WB24X5073 |
| 87 | WZ4X345D GE Screw Package 12 C92 |
| 87 | GEN WB01X5475 |
| 87 | GEN WB24X5075 |
| 88 | GEN WB02 |
| 90 | GEN WB56X1327 |
| 91 | GEN WB07X0636 |
| 91 | GEN WZ04X0237 |
| 92 | GEN WB10X0154 |
| 92 | GEN WB10 |
