JMC5200BAW14 03 – MICROWAVE OVEN CAVITY PARTS

Written by

Products

Position	Product
1	DE97-00585B Samsung Assembly Sensor-Humidity
1	SENSOR, GAS
2	DE47-20173A Samsung Thermostat
3	DE71-60449A Samsung Mounting Cover
4	PANEL-OUTER (WHT)
6	TRAY-COOKING
7	COUPLER
8	ASSY-GUIDE ROLLER,MR87/MR89,PI
9	MOTOR-DRIVE
10	LEVER-DOOR
11	BRACKET-SENSOR
