KAWE960WAL0 03 – CONTROL PANEL

Products

PositionProduct
18528351 Whirlpool Clip
6WP689559 Whirlpool Nut
7Trim, End Cap (L.H.)
8Cap, End (L.H.)
11Bracket, Control
12WPL 313087
13Connector, Two Terminal
14Board, Control
15Switch, Water Level
16Support, Circuit Board
17Relay, Power Control Board
19Support, Power Control
21Touch Module
26Cap, End (R.H.)
27Trim, End Cap (R.H.)
30Panel, Control Board and Standoff Mounting (8)
34WP90767 Whirlpool Screw
36WPL 64211
39Nut, Lock
41WP3351614 Whirlpool Screw
