KAWL400WAL0 04 – CONTROL PANEL
Written by
in
KAWL400WAL0 04 – CONTROL PANEL
Products
Position
Product
1
285952 Whirlpool Timer Assembly
2
Switch, Water Level
3
Bracket, Control
4
Cap, End (L.H.)
5
Switch, Water Temperature (Alt.)
5
Switch, Water Temperature
5
Switch, Water Temperature (Alt.)
6
WP90767 Whirlpool Screw
7
WP689559 Whirlpool Nut
8
WPL 64211
9
Console, Panel
10
Cap, End (R.H.)
11
Trim, Endcap (L.H.)
12
Knob, Timer
13
Trim, Endcap (R.H.)
14
WP3351614 Whirlpool Screw
15
WP356418 Whirlpool Screw
16
Knob, Adjustable Buzzer
16
Knob, Water Level Switch
18
Dial, Timer
19
WP688805 Whirlpool Spring Clip
←
