KB122G0 04 – BODY PARTS

Products

Position	Product
*46679	5303284616 Frigidaire Range Bulb Clip Thermostat
*46687	INSULATION VENT
*46686	WCI Q318054
*46686	INSULATION TOP/BOT
*46684	INSULATION TOP
*46682	INSULATION WRAP
*46677	BUTTON PLUG
1	WCI Q279959
2	WRAPPER INNER TOP
3	TRIM TOP
4	WRAPPER OUTER TOP
5	WCI 554T356F01
6	CONNECTR CONDUIT
7	BUSHING-INSULATOR
8	END CAP TOP (2)
9	WCI 740T328P17
9	WCI 740T328P18
10	WCI Q279958
11	FLUE BOX VERTICAL
12	WCI 072T476F01
13	SPRING (2)
14	SLEEVE DR SPRING (2)
15	WCI 647T081P04
16	END CAP BTM RH
16	END CAP BTM LH
17	WCI 036T034F02
18	WCI 117T014S09
18	WCI 117T014S10
19	TRIM LOWER
20	SEAL DOOR SIDE (2)
21	SHIELD BULB
22	WCI Q63749
23	WCI 662T012P08
24	TRIM TOP
25	FLUE BOX HORZ
26	WCI Q279960
27	RACK
28	WCI Q279946
29	WCI Q279947
30	GLIDE OV RACK (2)
