KC935KDD2 10 – POWER CONTROL

Products

Position	Product
*14177	WCI 299T405S203
*14177	WCI 3091206
*14177	HARNESS MAIN
*14177	WCI 299T400S197
2	SWITCH
3	FUSE
4	SOCKET
5	FAN BLADE TRANSFORMER
6	MOTOR FAN
7	ROD MOTOR (2)
8	CHANNEL
9	WCI 3091303
11	TRANSFORMER HV
12	SCRW. TRANSFORMR. MTG. 1/4-20 X 1/2“ (4)
12A	SCREW, TRANS (4)
13	RETAINER
14	SHIELD CAPACITOR
15	CAPAC HI VOLT. NON PCP
16	TRANSFORMER LV
17	SWITCH KIT (+)
18	TRIAC, HEAT SINK
19	SCREW (2)
20	WCI 554T338F02
21	NUT (2)
22	WCI 742T005P01
23	SCREW (8) (NON-ILLUSTRATED)
